Amigo E-Line User Manual

9. Technical specifications
E-bike parameters
Charger parameters
Dimensions (L × W × H)
1900 × 700 × 1180mm
Full Charging time
6,22 hours
Weight
≤ 25kg
Input voltage
220V/60Hz
Maximum speed
25 km/h
Maximum performance
60 Watts
Maximum load
≤ 120kg
Wheelbase between front/rear wheel hubs
1135 ± 5mm
Power consumption per 1000 km
1.2 kW/h
Control unit parameters
Low voltage protection
31.5 ± 1 Volts
Over-voltage protection
15 ± 1 Amperes
Motor parameters
Motor type
Brushless permanent
magnet motor
Rated output
250 Watts
Battery parameters
Rated voltage
36 Volts
Battery type
Lithium-ion battery
Rated torque
7Nm/32Nm
Capacity
8.7 Ah
Motor effectiveness
>75%
Battery voltage
36 Volts
Tyres
Maximum tyre pressure
3,5 – 6 BAR
