MST/D-431 - 4.3" S Series Touch Panels
18
Modero S Series Touch Panels - Installation & Hardware Reference Manual
MST/D-431 - 4.3" S Series Touch Panels
MST-431 (Tabletop)
MST-431 Specifications
FIG. 10 MST-431
MST-431 Specif ications
DIMENSIONS (HWD) 3 1/4" x 5 1/16" x 3 1/8" (82mm x 128mm x 79mm)
WEIGHT 0.9 lbs (.4 Kg)
POWER CONSUMPTION • Full-On: 4W
•Typical: 3W
•Standby: 2W
• Shutdown: 0.7W
• Start-Up Inrush Current: Not applicable due to PoE standard
EXTERNAL POWER SUPPLY
REQUIRED
Optimal performance requires use of one of the following AMX PoE power supplies (not included):
• PS-POE-AF-TC, PoE Injector, 802.3AF Compliant (FG423-83)
• NXA-ENET8-2POE, Gigabit PoE Ethernet Switch (FG2178-63)
CERTIFICATIONS • FCC Part 15 Class B
• CE EN 55022
• CE EN 55024
• CE EN 60950-1
•IEC 60950-1
• C-Tick CISPR 22 Class B
• IC CISPR 22 Class B
•UL 60950-1
• VCCI CISPR 22 Class B
•RoHS
•WEEE
TOUCH SCREEN DISPLAY • Display Type: TFT Active Matrix Color LCD
• Display Size (WH): Landscape: 5" x 3.4" (128mm x 87mm), 6" (152mm) diagonal
• Viewable Area (WH): Landscape: 3.7" x 2.1" (95mm x 54mm), 4.3" (109mm) diagonal
• Resolution: Landscape: 480x272
• Aspect Ratio: Landscape: 16:9
• Brightness: 350 cd/m2
• Contrast Ratio: 600:1
• Color Depth: 16.7M colors
• Illumination: LED
•Touch Overlay: Resistive
VIEWING ANGLE 40°/80°/65°/65° (Up/Down/Left/Right)
MEMORY • SDRAM: 512 MB
•Flash: 4 GB
• Maximum Project Size: 2.4 GB flash available to user
Sleep Button
Microphone
USB Port
