AMX PLB-AMP8 User Manual

PHASTLink Cable Information
7
A
ppendix: PHASTLink Cable Information
PhastLink Connections
FIG. 3 shows how PHASTLink and HubLink ports are connected in a Landmark system.
FIG. 3 PHASTLink ports connected in a typical Landmark system
PLB-CF10 CardFrame
HubLink
OUT IN
PLH-RPT Hub
HubLink
OUT IN
PHASTLink
12 13 14 15
Device
PHASTLink
Device
PLH-MIC Hub
HubLink
OUT IN
DMS
8
PHASTLink MIC
7
PHASTLink MIC
Terminate the
unused port
Terminate the
unused port
