Ansul 100/30 User Manual

To operate the ANSUL system:
1. Pull the Quick-Opening operating lever on nitrogen cylinder.
2. Pull ring pin and pull all hose from support.
3. Open nozzles fully. (Be prepared for a strong nozzle reaction.)
4. Direct streams at base of flames with a side-to-side motion.
System must be recharged immediately after use. See
Recharge Section. Protection for personnel and property is
not available until system is recharged.
IMPORTANT
If the system cannot be actuated by using
the Quick-Opening operating lever, turn
cylinder handwheel counterclockwise to
full open position.
THEN
Complete steps 2 through 4.
!
CAUTION
OPERATION
2012-MAR-22 REV. 01 PAGE3
ANSUL Fire Suppression/Securing Systems
Operation and Maintenance – Model 100/30

Ansul 100/30 Specifications

General

Brand	Ansul
Model	100/30
Category	Security System
Language	English
