| 18
8. Repairs
Repairs are only to be done by an authorized service
center.
9. Recommendations
Caution
Only install the pump in a lockable room, out of the reach of
children.
Ensure the motor’s cooling. The installation site must be dry and
well ventilated.
Never obstruct the air supply to the fan by putting any objects on
the pump or too close to the pump.
10. Technical data
* Explanation of water temperature 40 (60) °C:
40°C: maximumwatertemperatureascertifiedbytheGSapproval.
(60°C):pump in its current design is however usable/designed for a maximum water temperature of 60 °C.
Subject to technical modifications!
Technical data at 50 Hz AQUA VARIO PLUS
min. 1000 min
-1
max. 2850 min
-1
Inlet / outlet d (mm) 50 / 50
Rec. inlet / outlet pipe, PVC-pipe, d 50 / 40
max. L (mm) 532
Power input P
¹
(kW) 1~ 230 V 0.07 0.65
Power output P
²
(kW) 1~ 230 V 0.03 0.45
Rated current (A) 1~ 230 V 0.6 3
Lpa (1m) / dB(A) 45.1 63.9
Lwa / dB(A) 53.0 72.0
Type of motor enclosure IP 55 For standard voltage according to DIN IEC 60038 and
Thermal class B DIN EN 60034 (Euro-voltage).
Water temperature 40 (60)* Suitable for continuous operation at 1~ 220 - 240 V
Max. casing interior pressure (bar) 2.5 Tolerance ± 5%
Weight (kg) 6.4
1)
Measured with a phonometer according to DIN 45635.
