FOR MODELS: JGW, JGR AND JGJ SECTION 1 - DESIGN SPECIFICATIONS & DATA
PAGE 1 - 16 1/01
Valve Cap/Cylinder Head/Unloader/Gas Passage
Cap - Cap Screw
a
3/8 - 16 Hex - Grade 8 or 9 or
12 Point - Grade B7M
or 8
193 lb x in. (22)
7/16 - 14 26 (35)
1/2 - 13 40 (54)
5/8 -11 79 (105)
3/4 - 10 140 (190)
7/8 - 9 230 (310)
7/8 -14 260 (350)
1 - 8 345 (465)
Piston Rod Oil Slinger - Lock Nut 1/4 - 28 Hex - Jam 96 lb x in. (11)
Hold Down - Studnut 7/8 - 9 Hex Stud - nut
280
b
(380)
Rupture Disk - Blow-Out Fitting Cap 1/4 Nom. Tube Hex - Tube Fitting 36 lb x in. (4.1)
Tandem Cylinder to Cylinder - Cap Screw
a
1/2 - 13 Hex - Grade 8 or 9 or
12 Point - Grade 8
44 (60)
5/8 - 11 88 (120)
3/4 - 10 160 (215)
Seating Studs in Cylinder 3/8 - 16 Dog Point 107 lb x in. (12)
7/16 - 14 172 lb x in. (19)
1/2 - 13 22 (30)
9/16 - 12 32 (43)
5/8 - 11 44 (60)
3/4 - 10 79 (105)
7/8 - 9 130 (170)
1 - 8 190 (260)
Distribution Block Tie Rod - Nut 1/4 - 28 Hex 68 lb x in. (7.7)
Distribution Block Divider Valve - Screw 1/4 - 28 Socket Head 109 lb x in. (12)
Grade 5 - Hex Cap Screw All Hex - Grade 5 Hand Wrench
Tight
a. When studs are specified for cylinder applications, tighten stud-nuts to the same values as cap screws
in similar applications. Reference Figure 1-8:
b. Minimum torque for recommended 7/8” - 9 TPI hold down stud size to provide stress in stud of 55,000
psi (380 MPa). Stud must have an ultimate strength of 100,000 psi (690 MPa) or greater. If greater,
increase torque to stress stud to about 55% of the ultimate strength of the stud material, as specified by
packager.
TABLE 1-11: FASTENER TIGHTENING VALUES
FASTENER
NOMINAL SIZE,
INCH - TPI
TYPE
TORQUE,
LB X FT (N·m)
