Aritech 1X-F Series User Manual

1X-F Series Operation Manual 5
Operator controls and indicators
The following table gives an overview of the control panel operator controls and
indicators. Item numbers refer to Figure 1 on page 3 and Figure 2 on page 4.
Operational features described here may not be available to all users. Further
information on control panel operation and access restrictions can be found in
the topic “Control panel operation” on page 13.
Table 5: Operator controls and LED indicators
Item
Control/LED LED colour Description
1
Zone buttons and
LEDs
Red/Yellow Disables or tests a zone (when pressed with the
General Disable or General Test button).
A red LED indicates an alarm in the
corresponding zone.
A flashing red LED indicates that the fire alarm
was activated by a detector. A steady red LED
indicates that the fire alarm was activated by a
manual call point.
A yellow LED indicates a fault, test, or
disablement in the corresponding zone.
A flashing yellow LED indicates a fault. A steady
yellow LED indicates that the zone is disabled or
is being tested.
2
Supply LED Green Indicates that the system is powered up correctly.
3
General Fault LED Yellow
Indicates a fault. The corresponding zone, device,
or function fault LED also flashes.
4
General Fire Alarm
LEDs
Red Indicates a fire alarm.
Flashing LEDs indicate that the fire alarm was
activated by a detector.
Steady LEDs indicate that the fire alarm was
activated by a manual call point.
The corresponding zone alarm LED indicates the
source of fire alarm.
5
Sounder
Fault/Disable/Test
button and LED
— or —
Evacuation
Fault/Disable/Test
button and LED for
NBN S 21-100)
Yellow Disables or tests sounders (when pressed with
the General Disable or General Test button).
A flashing LED indicates a fault with the sounders
or evacuation sounders. A steady LED indicates
that the sounders or evacuation sounders are
disabled or are being tested.
