DIGITAL VIDEO RECORDER QUICK START GUIDE
WHAT’S IN THE BOX
*Not required with DVR-2M-4-2 & DVR-8M-4
1. INSTALLATIO N
Rear Panel
1
–
DVR
-
2M
-
4
-
2
DVR
-
8M
-
4
DVR
-
8M
-
8 & DVR
-
2M
-
8
-
2
DVR
-
2M
-
16
-
2
DVR
-
8M
-
16
DVR
-
2M
-
32
No.
Name
Description
1
CAM1 – CAM4 (DVR-2M-4-2, DVR-8M-4)
CAM1 – CAM8 (DVR-2M-8-2, DVR-8M-8)
CAM1 – CAM16 (DVR-2M-16-2, DVR-8M-16)
CAM1
–
CAM32 (DVR
-
2M
-
32)
BNC connectors used for connecting
HD analogue cameras
2 ETHERNET/WAN
Network port for connection to the
Internet, router, network switch &
network IP cameras (no POE from this
port)
3
VGA
VGA display output for connection to
a main display monitor (Max.
1920x1080 display resolution).
4
HDMI (DVR
-
8
M
-
4/8
/16
)
HDMI display output for connection a
main display monitor (Max.
3840x2160 display
resolution).
HDMI (DVR
-
2M
-
4
-
2
/8
-
2
/16
-
2
/32)
HDMI display output for connection a
main display monitor (Max.
Technical Documents
DVR
USB Mouse
Remote Control*
DC 12V PSU (4ch/ 8ch/ 16ch)
HDD Mounting Screws Rack Mount Ears (16ch/ 32ch)
UK Kettle Lead (8ch/ 16ch/ 32ch)* Quick Start Guide
QR Code
