2727
2727
27
3.1.23.1.2
3.1.23.1.2
3.1.2
Navigation KeysNavigation Keys
Navigation KeysNavigation Keys
Navigation Keys
Please check the following table for the function description of each navigation
key.
Navigation Key(s) Function Description
/ Moves cursor left or right to select Screens
/ Moves cursor up or down to select items
+ / - To change option for the selected items
<Enter> To bring up the selected screen
<F1> To display the General Help Screen
<F9> To load optimal default values for all the settings
<F10> To save changes and exit the BIOS SETUP UTILITY
<ESC> To jump to the Exit Screen or exit the current screen
3.23.2
3.23.2
3.2
Main ScreenMain Screen
Main ScreenMain Screen
Main Screen
When you enter the BIOS SETUP UTILITY, the Main screen will appear and display
the system overview
G41M-GS3
System Time [Hour:Minute:Second]
Use this item to specify the system time.
System Date [Day Month/Date/Year]
Use this item to specify the system date.
BIOS SETUP UTILITY
Main
OC Tweaker H/W Monitor Boot Security ExitAdvanced
System Overview
System Time
System Date
[ :00:09]
[Fri 10/16/2009]
Use [Enter], [TAB]
or [SHIFT-TAB] to
select a field.
Use [+] or [-] to
configure system Time.
Select Screen
Select Item
+- Change Field
Tab Select Field
F1 General Help
F9 Load Defaults
F10 Save and Exit
ESC Exit
v02.54 (C) Copyright 1985-2005, American Megatrends, Inc.
14
BIOS Version
Processor Type
Processor Speed
Microcode Update
Cache Size
Total Memory
DDR3_1
DDR3_2
: G41M-GS3 P1.00
: Intel (R) Core (TM) 2 Duo CPU
E6850 @ 3.00GHz (64bit)
: 3148MHz
: 6FB/B6
: 1024KB
: 1024MB with 128MB shared memory
and 2MB GTT memory
Single-Channel Memory Mode
: 1024MB/400MHz DDR3_800
:None
To Next Page
