ASROCK X570 Steel Legend User Manual

English
8
Purity
Sound 4
TM
DDR4_A2 (64 bit, 288-pin module)
DDR4_A1 (64 bit, 288-pin module)
DDR4_B2 (64 bit, 288-pin module)
DDR4_B1 (64 bit, 288-pin module)
ATXPWR1
PCIE1
Top:
Central/Bass
Cen ter:
REA R SPK
Top:
LIN E IN
Cen ter:
FRO NT
Bot tom:
Opt ical
SPD IF
Bot tom:
MIC I N
PCIE4
HDLED RESET
PLED PWRBTN
PANEL1
1
1
SPK_PLED1
1
HD_AUDIO1
SATA3 _1 _2
SATA3 _3 _4
SATA3 _7 _8
8
10
11
12
13
14
SATA3 _5 _6
15
16
USB_1_2
1
20
USB_3_4
1
19
29
1
6
5
28
USB 3. 2 Ge n1
T: USB1
B: USB 2
PS2
Keyb oar d
/Mou se
CMOS
Battery
23
22
CPU_FAN1
9
1
TPMS1
USB 3.2 Gen2
T: USB31_TA_1
B: USB31_TC_1
M2_2
M2_1
CHA_FAN1/WP
CPU_FAN2/WP
4
3
USB 3_7_8
1
LAN
17
RoHS
PCIE5
ATX 12V1
1
USB_5
AMD
Premium
X570
SOCKETAM4
CHA_FAN3/WP
24 21
ADDR_LED1
PCIE3
HDMI1
2
ATX 12V2
27
BIOS
ROM
USB 3.2 Gen1
T: USB5
B: USB6
Top:
RJ-45
T B1
1
RGB_HEADER1
1
1
AMD_FAN_LED1
1
CLRCMOS1
1
18
X57 0 Steel Legend
USB 3_9_1 0
1
7
CHA_FAN4/WP
CHA_FAN2/WP
25
26
1
SPI_TPM_J1
PCIE2
M2_WIFI_1
30
31
USB 3.2 Gen1
T: USB3
B: USB4
Supe r
I/O
DISPL AY1
CPU
DRAM
VGA
BOOT
1.3 Motherboard Layout

ASROCK X570 Steel Legend Specifications

General

Processor socket	Socket AM4
Processor manufacturer	AMD
Compatible processor series	AMD Ryzen 3 2nd Gen, AMD Ryzen 3 3rd Gen, AMD Ryzen 5 2nd Gen, AMD Ryzen 5 3rd Gen, AMD Ryzen 7 2nd Gen, AMD Ryzen 7 3rd Gen, AMD Ryzen 9 3rd Gen
Audio chip	Realtek ALC1220
Certification	FCC, CE, ErP/EuP
Component for	PC
Motherboard chipset	AMD X570
Audio output channels	7.1 channels
Motherboard form factor	ATX
Windows operating systems supported	Windows 10 x64
ECC	Yes
Memory channels	Dual-channel
Memory slots type	DIMM
Number of memory slots	4
Supported memory types	DDR4-SDRAM
Maximum internal memory	128 GB
Supported memory clock speeds	2133, 2400, 2667, 2933, 3200, 3466, 3600, 4133, 4200, 4266, 4300, 4400 MHz
BIOS type	UEFI AMI
ACPI version	5.1
BIOS memory size	256 Mbit
System Management BIOS (SMBIOS) version	2.3
DirectX version	12.0
Maximum resolution	4096 x 2160 pixels
Parallel processing technology support	-
DisplayPort version	1.2
PS/2 ports quantity	1
USB 2.0 ports quantity	0
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	6
LAN controller	Intel® I211-AT
Ethernet interface type	Gigabit Ethernet
Weight	1500 g
Number of M.2 (M) slots	2
Number of SATA III connectors	8
Supported storage drive interfaces	M.2, PCI Express 3.0, SATA III
Harmonized System (HS) code	84733020

Weight and Dimensions

Depth	244 mm
Width	305 mm
Height	87 mm
