ASROCK X570 Taichi Manual

English
7
X570 Taichi
1.2 Specications
Platform
•
ATX Form Factor
•
2oz Copper PCB
CPU
•
Supports AMD AM4 socket Ryzen™ 2000 and 3000 series
processors
•
Intersil Digital PWM
•
14 Power Phase design
•
Supports ASRock Hyper BCLK Engine II
Chipset
•
AMD X570
Memory
•
Dual Channel DDR4 Memory Technology
•
4 x DDR4 DIMM Slots
•
AMD Ryzen series CPUs (Matisse) support DDR4
4666+
(OC)/4400(OC)
/4300(OC)/4266(OC)/4200(OC)/4133
(OC)/3466(OC)/3200/2933/2667/2400/2133 ECC & non-
ECC, un-buered memory*
•
AMD Ryzen series CPUs (Pinnacle Ridge) support DDR4
3600+(OC)/3466(OC)/3200(OC)/2933/2667/2400/2133 ECC
& non-ECC, un-buered memory*
•
AMD Ryzen series CPUs (Picasso) support DDR4 3466+
|
(OC)/3200(OC)/2933/2667/2400/2133 non-ECC, un-buered
memory*
* For Ryzen Series CPUs (Picasso), ECC is only supported with
PRO CPUs.
* Please refer to Memory Support List on ASRock’s website for
more information. (http://www.asrock.com/)
* Please refer to page 26 for DDR4 UDIMM maximum
frequency support.
•
Max. capacity of system memory: 128GB
•
15μ Gold Contact in DIMM Slots
Expansion
Slot
AMD Ryzen series CPUs (Matisse)
•
3 x PCI Express 4.0 x16 Slots (PCIE1/PCIE3/PCIE5: single
at x16 (PCIE1); dual at x8 (PCIE1) / x8 (PCIE3); triple at x8
(PCIE1) / x8 (PCIE3) / x4 (PCIE5))*

ASROCK X570 Taichi Specifications

General

Processor socket	Socket AM4
Processor manufacturer	AMD
Compatible processor series	AMD Ryzen 3 2nd Gen, AMD Ryzen 3 3rd Gen, AMD Ryzen 5 2nd Gen, AMD Ryzen 5 3rd Gen, AMD Ryzen 7 2nd Gen, AMD Ryzen 7 3rd Gen, AMD Ryzen 9 3rd Gen
Audio chip	Realtek ALC1220
Certification	FCC, CE, ErP/EuP ready
Component for	PC
Motherboard chipset	AMD X570
Audio output channels	7.1 channels
Motherboard form factor	ATX
Windows operating systems supported	Windows 10 x64
ECC	Yes
Memory channels	Dual-channel
Memory slots type	DIMM
Number of memory slots	4
Supported memory types	DDR4-SDRAM
Maximum internal memory	128 GB
Supported memory clock speeds	2133, 2400, 2667, 2933, 3200, 3466, 4133, 4200, 4266, 4300, 4400 MHz
BIOS type	UEFI AMI
ACPI version	5.1
BIOS memory size	256 Mbit
System Management BIOS (SMBIOS) version	2.3
Graphics card	Radeon Vega
DirectX version	12.0
Maximum resolution	4096 x 2160 pixels
Parallel processing technology support	-
PS/2 ports quantity	1
WiFi-AP antenna jack	2
USB 2.0 ports quantity	0
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	6
LAN controller	Intel® I211-AT
Wi-Fi standards	802.11a, 802.11ad, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax)
Bluetooth version	5.0
Ethernet interface type	Gigabit Ethernet
Number of M.2 (M) slots	3
Number of SATA III connectors	8
Bundled software	Software - ASRock Polychrome SYNC - ASRock XFast LAN UEFI - ASRock Full HD UEFI - ASRock Instant Flash - ASRock Easy RAID Installer
Supported storage drive interfaces	PCI Express 3.0, SATA III
Harmonized System (HS) code	84733020
Weight	1500 g

Weight and Dimensions

Depth	244 mm
Width	305 mm
Height	350 mm
