22
Notebook PC User Manual
Left Side
3
Intel Series
AMD Series
Air Vents
The air vents allow cool air to enter and warm air to exit the
Notebook PC.
Power (DC) Input
The supplied power adapter converts AC power to DC power
for use with this jack. Power supplied through this jack
supplies power to the Notebook PC and charges the internal
battery pack. To prevent damage to the Notebook PC and
battery pack, always use the supplied power adapter.
The adapter may become warm to hot when in use. Ensure not
to cover the adapter and keep it away from your body.
LAN Port
The RJ-45 LAN port with eight pins is larger than the RJ-11
modem port and supports a standard Ethernet cable for
connection to a local network. The built-in connector allows
convenient use without additional adapters.
1
2
To Next Page
