ASUS F1A55-M LE R2.0
1-7
1.3.4 Layout contents
Connectors/Jumpers/Slots/LED Page
1. ATX power connectors (24-pin EATXPWR, 4-pin ATX12V) 1-27
2. Power, CPU, and chassis fan connectors (3-pin PWR_FAN, 4-pin CPU_FAN
and 3-pin CHA_FAN)
1-26
3. AMD FM1 socket 1-8
4. DDR3 DIMM slots 1-11
5. SATA 3.0Gb/s connectors (7-pin SATA3G_1~6) 1-28
6. Clear RTC RAM (3-pin CLRTC) 1-23
7. Standby power LED (SB_PWR) 1-4
8. System panel connector (10-1 pin F_PANEL) 1-30
9. Speaker connector (4-pin SPEAKER) 1-26
10. USB 2.0 connectors (10-1 pin USB56, USB78, USB910) 1-32
11. Digital audio connector (4-1 pin SPDIF_OUT) 1-31
12. LPT connector (26-1 pin LPT) 1-30
13. Front panel audio connector (10-1 pin AAFP) 1-31
14. Serial port connector (10-1 pin COM1) 1-29

Asus F1A55-M LE R2.0 Specifications

General

ECC	No
Non-ECC	Yes
Internal memory	32 GB
Memory channels	Dual-channel
Memory slots type	DIMM
Number of memory slots	2
Supported memory types	DDR3-SDRAM
Supported memory clock speeds	1066, 1333, 1600, 1866, 2250 MHz
Processor socket	Socket FM2
Processor manufacturer	AMD
Compatible processor series	AMD A, AMD E2
USB 2.0 connectors	3
Number of COM connectors	1
Number of SATA connectors	6
USB 3.2 Gen 1 (3.1 Gen 1) connectors	0
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Audio chip	Realtek ALC887
Cooling type	Passive
Component for	PC
Power source type	ATX
Motherboard chipset	AMD A55 FCH
Audio output channels	7.1 channels
Motherboard form factor	micro ATX
RAID levels	0, 1, 3, 10, JBOD
Supported storage drive interfaces	SATA, SATA II, SATA III
Graphics card	Radeon HD 6000
DirectX version	11
Maximum resolution	1920 x 1200 pixels
Parallel processing technology support	Not supported
PCI Express slots version	2.0
Cables included	SATA
BIOS type	UEFI
ACPI version	2.0a
BIOS memory size	64 Mbit

Weight and Dimensions

Depth	229 mm
Width	244 mm
