Asus F1A55-M LE R2.0 User Manual

ix
(continued on the next page)
F1A55-M LE R2.0 specications summary
APU AMD
®
A- & E2- series accelerated processors with AMD
®
Radeon™ HD
6000 series graphics, up to 4 CPU cores, FM1 package
DirectX
®
11 support
AMD
®
Turbo Core Technology 2.0 support
• The AMD
®
Turbo Core Technology 2.0 support depends on the APU types.
• Refer to www.asus.com for the AMD® CPU support list
Chipset AMD
®
A55 FCH (Hudson D2)
Memory Dual-channel memory architecture
2 x 240-pin DIMM slots support maximum 32GB unbuffered non-ECC
DDR3 2250(O.C.) / 1866 /1600/ 1333/ 1066 MHz memory modules
• The maximum 32GB memory capacity can be supported with 16GB or above
DIMMs. ASUS will update the memory QVL once the DIMMs are available in the
market.
• Refer to www.asus.com for the latest Memory QVL (Qualied Vendors List).
• When you install a total memory of 4GB capacity or more, Windows
®
32-bit
operating system may only recognize less than 3GB. We recommend a
maximum of 3GB system memory if you are using a Windows
®
32-bit operating
system.
Graphics Integrated AMD
®
Radeon™ HD 6000 series graphics in the Liano APU
Dual independent displays support: DVI and D-Sub
Supports DVI with max. resolution up to 1920 x 1200 @60Hz
Supports D-Sub with max. resolution up to 1920 x 1600 @60Hz
Supports Microsoft
®
DirectX 11
Supports AMD
®
Dual Graphics technology
• Refer to www.amd.com for the discrete GPUs that support Dual Graphics.
Multi-GPU support Supports LucidLogix Virtu MVP Technology
• LucidLogix Virtu MVP supports Windows
®
7 operating system.
Expansion slots 2 x PCIe 2.0 x16 slots with ATI
®
CrossFireX™ support (blue @x16 mode,
black @x4 mode)
1 x PCIe 2.0 x1 slot
1 x PCI slot
Storage
AMD
®
A55 FCH southbridge
- 6 x Serial ATA 3.0Gb/s connectors support RAID 0, RAID 1, RAID 10,
and JBOD congurations
LAN
Realtek
®
8111E/F Gigabit LAN controller
Audio Realtek ALC887 3-jack 8-channel High Denition Audio CODEC
- Supports jack-detection,multi-streaming, and front panel jack retasking
USB
AMD
®
A55 FCH southbridge
- 12 x USB 2.0/1.1 ports (6 ports at the mid-board, 6 ports at the back
panel)
ASUS unique
features
100% All High-Quality conductive polymer capacitors
ASUS Hybrid DIGI+VRM
- 4+2 Phase Power Design
ASUS Unique Technology
- TurboV
- EPU

Asus F1A55-M LE R2.0 Specifications

General

ECC	No
Non-ECC	Yes
Internal memory	32 GB
Memory channels	Dual-channel
Memory slots type	DIMM
Number of memory slots	2
Supported memory types	DDR3-SDRAM
Supported memory clock speeds	1066, 1333, 1600, 1866, 2250 MHz
Processor socket	Socket FM2
Processor manufacturer	AMD
Compatible processor series	AMD A, AMD E2
USB 2.0 connectors	3
Number of COM connectors	1
Number of SATA connectors	6
USB 3.2 Gen 1 (3.1 Gen 1) connectors	0
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Audio chip	Realtek ALC887
Cooling type	Passive
Component for	PC
Power source type	ATX
Motherboard chipset	AMD A55 FCH
Audio output channels	7.1 channels
Motherboard form factor	micro ATX
RAID levels	0, 1, 3, 10, JBOD
Supported storage drive interfaces	SATA, SATA II, SATA III
Graphics card	Radeon HD 6000
DirectX version	11
Maximum resolution	1920 x 1200 pixels
Parallel processing technology support	Not supported
PCI Express slots version	2.0
Cables included	SATA
BIOS type	UEFI
ACPI version	2.0a
BIOS memory size	64 Mbit

Weight and Dimensions

Depth	229 mm
Width	244 mm
