Asus F1A55-M LK R2.0 User Manual

AMD
®
A55 (Hudson D2) FCH Chipset
AMD
®
A55 FCH (Hudson D2) is designed to support up to 5GT/s interface
and PCI Express 2.0 x 16 (at x4 speed) graphics.
8-channel high denition audio
The onboard 8-channel HD audio (High Denition Audio, previously
codenamed Azalia) CODEC enables high-quality 192KHz/24-bit audio
output and jack-detect feature that automatically detects and identies
what types of peripherals are plugged into the audio I/O jacks and noties
users of inappropriate connection, which means there will be no more
confusion of Line-in, Line-out, and Mic jacks.
Gigabit LAN solution
The onboard LAN controller is a highly integrated Gb LAN controller. It is
enhanced with an ACPI management function to provide efcient power
management for advanced operating systems.
1.3.2 ASUS DIGI+ VRM
DIGI+ Power Control: Digital Power Design for the APU*
ASUS motherboards using the AMD
®
A55 chipset employ precise digital
voltage regulation for the CPU, called DIGI+ VRM (Voltage Regulation
Modules) digital power design. The CPU voltage and VRM frequency
are adjusted via either carefully developed automated modes, or by
using user-dened proles. The effect is that DIGI+ VRM technology
ensures greater energy efciency and the most precise power delivery.
Boosted by world-renowned ASUS quality, it creates an ideal computing
platform for a diverse range of applications, from gaming to multimedia
or ofce work and heavy multitasking. Engineered and tested to assure
unmitigated performance, ASUS A55 boards with DIGI+ VRM remain
efcient and accurate, for reliable application in every scenario.
* DIGI+ VRM functions also available in FM1 socket compatible CPUs.
EPU
Tap into the world’s rst real-time PC power saving chip through the AI
Suite II utility. Get total system-wide energy optimization by automatically
detecting current PC loadings and intelligently moderating power
consumption. This also reduces fan noise and extends component
longevity.
Chapter 1: Product introduction1-2

Asus F1A55-M LK R2.0 Specifications

General

Non-ECC	Yes
Memory channels	Dual-channel
Memory slots type	DIMM
Number of memory slots	2
Supported memory types	DDR3-SDRAM
Maximum internal memory	32 GB
Supported memory clock speeds	1066, 1333, 1600, 1866 MHz
Processor socket	Socket FM1
Processor manufacturer	AMD
Compatible processor series	AMD A, AMD E2
Maximum number of SMP processors	1
Number of SATA II connectors	4
USB 3.2 Gen 1 (3.1 Gen 1) connectors	-
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Audio chip	Realtek ALC887
Cooling type	Passive
Component for	PC
Power source type	ATX
Motherboard chipset	AMD A55
Audio output channels	7.1 channels
Motherboard form factor	micro ATX
RAID levels	0, 1, 10, JBOD
Supported storage drive interfaces	SATA II
Graphics card	Radeon HD 6000
DirectX version	11
Maximum resolution	1920 x 1200 pixels
Parallel processing technology support	LucidLogix Virtu
PCI Express slots version	2.0
PCI Express configurations	1x1, 1x16
Trial software	Antivirus
Cables included	SATA
Bundled software	ASUS Utilities ASUS Update
Ethernet interface type	Gigabit Ethernet
BIOS type	UEFI
ACPI version	2.0a
BIOS memory size	64 Mbit

Weight and Dimensions

Depth	186 mm
Width	226 mm
