Asus F1A55 R2.0 User Manual

xii
Package contents
Check your motherboard package for the following items.
ASUS F1A55 R2.0 motherboard 2 x Serial ATA 3.0 Gb/s cables
User Manual
1 x I/O-Shield User Guide Support DVD
• If any of the above items is damaged or missing, contact your retailer.
• The illustrated items above are for reference only. Actual product specications may
vary with different models.
F1A55 R2.0
PCIEX16_1
PCIEX16_2
PCIEX1_2 PCIEX1_1
PCI1 PCI2 PCI3
USB78USB910USB1112
PANEL
SPDIF_OUT
AAFP
CPU_FAN
CHA_FAN1
PWR_FAN
CHA_FAN2
Lithium Cell
CMOS Power
Super
I/O
AUDIO
ALC
887
EPU
ASM
1042
ICS483A
COM1
KBMS
64Mb
BIOS
SB_PWR
CLRTC
AMD
®
A55 FCH
Realtek
®
8111E
DDR3 DIMM_A1 (64bit, 240-pin module)
DDR3 DIMM_A2 (64bit, 240-pin module)
DDR3 DIMM_B1 (64bit, 240-pin module)
DDR3 DIMM_B2 (64bit, 240-pin module)
LAN1_USB12
USB3_E12
USB34 USB56
SPDIF_O2
SATA3G_5
SATA3G_6
SATA3G_3
SATA3G_4
SATA3G_1
SATA3G_2
MemOK!
DRAM_LED
SOCKET FM1
EATXPWR
ATX12V

Asus F1A55 R2.0 Specifications

General

Non-ECC	Yes
Memory channels	Dual-channel
Memory slots type	DIMM
Number of memory slots	4
Supported memory types	DDR3-SDRAM
Maximum internal memory	64 GB
Supported memory clock speeds	1066, 1333, 1866, 2250 MHz
Processor socket	Socket FM1
Processor manufacturer	AMD
Compatible processor series	AMD A, AMD E2
Maximum number of SMP processors	1
USB 2.0 connectors	3
Number of SATA II connectors	6
Number of Parallel ATA connectors	-
USB 3.2 Gen 1 (3.1 Gen 1) connectors	0
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Audio chip	Realtek ALC887
Cooling type	Passive
Component for	PC
Motherboard chipset	AMD A55
Audio output channels	7.1 channels
Motherboard form factor	ATX
RAID levels	0, 1, 10, JBOD
Supported storage drive interfaces	SATA II
Graphics card	Radeon HD 6000
DirectX version	11
Parallel processing technology support	2-Way CrossFireX
PCI Express slots version	2.0
PCI Express configurations	1x4, 1x16, 2x1
Controller interface type	AMD A55 FCH
Trial software	Antivirus
Cables included	SATA
Bundled software	ASUS Utilities\\r ASUS Update
LAN controller	Realtek RTL8111E
Ethernet interface type	Gigabit Ethernet
BIOS type	UEFI
ACPI version	2.0a
BIOS memory size	64 Mbit

Weight and Dimensions

Depth	224 mm
Width	305 mm
