F2A55 specications summary
APU FM2 socket for AMD
®
A-Series accelerated processors (APU) with AMD
Radeon™ HD 7000 Series graphics, up to 4 CPU cores
AMD
®
Turbo Core Technology 3.0 support
• The AMD
®
Turbo Core Technology 3.0 support depends on the APU types.
• Refer to www.asus.com for the AMD
®
APU support list.
Chipset AMD
®
A55 FCH
Memory 4 x 240-pin DIMM slots support maximum 64GB unbuffered non-ECC DDR3
2400(O.C.)/2250(O.C.)/2200(O.C.)/2133(O.C.)1866/1600/1333/1066 MHz
memory modules
Dual-channel memory architecture
• The maximum 64GB memory capacity can be supported with 16GB or above
DIMMs. ASUS will update the memory QVL once the DIMMs are available in the
market.
• Refer to www.asus.com for the latest Memory QVL (Qualied Vendors List).
• When you install a total memory of 4GB capacity or more, Windows
®
32-bit
operating system may only recognize less than 3GB. We recommend a
maximum of 3GB system memory if you are using a Windows
®
32-bit operating
system.
Graphics Integrated AMD
®
Radeon™ HD 7000 series graphics in Trinity APU
Supports AMD
®
Dual Graphics
* Refer to www.amd.com for the discrete GPUs that support Dual Graphics.
Expansion slots 2 x PCIe 2.0 x16 slots (blue @x16 mode, black @x4 mode)
2 x PCIe 2.0 x1 slots
3 x PCI slots
Multi-GPU
support
Supports AMD
®
CrossFireX™ Technology
Storage / RAID AMD
®
A55 FCH:
- 6 x Serial ATA 3.0Gb/s connectors support RAID 0, RAID 1, RAID 10
and JBOD congurations
LAN Realtek
®
8111F PCIe Gigabit LAN controller
Audio ALC887 8-channel High Denition Audio CODEC
- Supports Jack-Detection, Multi-Streaming, and Front Panel Jack-
Retasking
- Supports S/PDIF out interface at the back I/O
USB AMD
®
A55 FCH:
- 12 x USB 2.0/1.1 ports (6 ports at the mid-board, 6 ports at the back
panel)
Asmedia
®
PCIe USB3.0 controller:
- 2 x USB 3.0/2.0 ports (blue, at the back panel)

Asus F2A55 Specifications

General

Non-ECC	Yes
Memory channels	Dual-channel
Memory slots type	DIMM
Number of memory slots	4
Supported memory types	DDR3-SDRAM
Maximum internal memory	64 GB
Supported memory clock speeds	1066, 1333, 1600, 1866, 2000, 2133, 2200, 2250, 2400 MHz
Processor socket	Socket FM2
Processor manufacturer	AMD
Compatible processor series	AMD Athlon
USB 2.0 connectors	3
Number of COM connectors	1
Number of SATA II connectors	6
USB 3.2 Gen 1 (3.1 Gen 1) connectors	0
RAID levels	0, 1, 10, JBOD
Supported storage drive interfaces	SATA II
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
LAN controller	Realtek 8111F
Ethernet interface type	Gigabit Ethernet
Audio chip	Realtek ALC887
Component for	PC
Motherboard chipset	AMD A55 FCH
Audio output channels	- channels
Motherboard form factor	ATX
Parallel processing technology support	-
BIOS type	UEFI
ACPI version	2.0a
Cables included	SATA

Weight and Dimensions

Depth	224 mm
Width	305 mm
