Asus H110M-D User Manual

ASUS H110M-D
1-5
1. PS/2 Keyboard/Mouse combo port.Thisportconnectstoa
PS/2mouseorPS/2keyboard.
2. LPT connector (25-pin LPT).Connectaparrallelportdevice
suchasaprintertothisLPT(LinePrintingTerminal)connector.
3. LAN (RJ-45) port.ThisportallowsGigabitconnectiontoa
LocalAreaNetwork(LAN)throughanetworkhub.
 LAN port LED indications
Rear panel connectors
4 53
678
2
910
1
11
LAN port
Speed
LED
Activity Link
LED
Activity/Link LED
Speed LED
Status Description
Status Description
Off Nolink OFF 10Mbpsconnection
Orange Linked ORANGE 100Mbpsconnection
Orange(Blinking) Dataactivity GREEN 1Gbpsconnection
Orange(Blinking
thensteady)
Readytowakeup
fromS5mode
_ _
4. Line In port (light blue).Thisportconnectstothetape,CD,DVDplayer,orother
audiosources.
5. Line Out port (lime).Thisportconnectstoaheadphoneoraspeaker.Inthe4.1,5.1
and7.1-channelcongurations,thefunctionofthisportbecomesFrontSpeakerOut.
6. Microphone port (pink).Thisportconnectstoamicrophone.
Refertotheaudiocongurationtableforthefunctionoftheaudioportsin2.1,4.1,5.1,or
7.1-channelconguration.

Asus H110M-D Specifications

General

Form Factor	Micro ATX
Chipset	Intel H110
Socket	LGA 1151
Memory Slots	2
Maximum Memory	32GB
Memory Type	DDR4
Memory Standard	DDR4 2133 MHz
PCIe x16 Slots	1
PCIe x1 Slots	2
SATA Ports	4 x SATA 6Gb/s
Audio	Realtek ALC887 8-Channel High Definition Audio CODEC
USB 3.0 Ports	2
USB 2.0 Ports	6 x USB 2.0 (2 at back panel, 4 at mid-board)
LAN	Realtek RTL8111H
Graphics Output	1 x DVI-D, 1 x VGA
