Asus H110M-D User Manual

Configuration fields
Menu bar
General helpSub-menu item
Menu items
Scroll bar
Last modified
settings
Language
Hot Keys
MyFavorite
Q-Fan control
Goes back to
EZ Mode
Displays the CPU temperature, CPU
and memory voltage output
Quick Note
Advanced Mode
TheAdvancedModeprovidesadvancedoptionsforexperiencedend-userstocongurethe
BIOSsettings.ThegurebelowshowsanexampleoftheAdvanced Mode.Refertothe
followingsectionsforthedetailedcongurations.
ToaccesstheEZMode,clickEzMode(F7)orpress<F7>.
Popup window
Search on
FAQs
ASUS H110M-D 2-3

Asus H110M-D Specifications

General

Form Factor	Micro ATX
Chipset	Intel H110
Socket	LGA 1151
Memory Slots	2
Maximum Memory	32GB
Memory Type	DDR4
Memory Standard	DDR4 2133 MHz
PCIe x16 Slots	1
PCIe x1 Slots	2
SATA Ports	4 x SATA 6Gb/s
Audio	Realtek ALC887 8-Channel High Definition Audio CODEC
USB 3.0 Ports	2
USB 2.0 Ports	6 x USB 2.0 (2 at back panel, 4 at mid-board)
LAN	Realtek RTL8111H
Graphics Output	1 x DVI-D, 1 x VGA
