ASUS M2A-MX 2-25
2.4.4 Onboard Devices Conguration
Congure ITE8712 Super IO Chipset
Serial Port1 Address [3F8/IRQ4]
Parallel Port [378]
Parallel Port Mode [Normal]
Parallel Port IRQ [IRQ7]
Congure Onboard Device
HDAudio Controller [Enabled]
Front Panel Select [HD Audio]
OnBoard LAN Controller [Enabled]
OnBoard LAN Boot Rom [Disabled]
Congure ITE8712 Super IO Chipset
Serial Port1 Address [3F8/IRQ4]
Allows you to select the Serial Port1 base address.
Conguration options: [Disabled] [3F8/IRQ4][2F8/IRQ3] [3E8/IRQ4] [2E8/IRQ3]
Parallel Port [378]
Allows you to select the Parallel Port base addresses.
Conguration options: [Disabled] [378] [278] [3BC]
Parallel Port Mode [Normal]
Allows you to select the Parallel Port mode.
Conguration options: [Normal] [EPP] [ECP] [EPP+ECP]
Parallel Port IRQ [IRQ7]
Allows you to select parallel port IRQ. Conguration options: [IRQ5] [IRQ7]
Congure Onboard Device
HDAudio Controller [Enabled]
Allows you to enable or disable the HD audio. Conguration options: [Disabled]
[Enabled]
Front Panel Select [HD Audio]
Allows you to select front panel . If High Denition Audio is used, set to HD Audio
mode. Conguration options: [AC97] [HD Audio]
OnBoard LAN Controller [Enabled]
Allows you to enable or disable onboard LAN. Conguration options: [Disabled]
[Enabled]
OnBoard LAN Boot ROM [Disabled]
Allows you to congure LAN boot ROM. Conguration options: [Disabled]
[Enabled]
Allows BIOS to Select
Serial Port1 Base
Addresses.
