ASUS M2N-E 5-29
Entering the NVIDIA
®
MediaShield RAID utility
To enter the NVIDIA
®
RAID utility:
1. Boot up your computer.
2. During POST, press <F10> to display the main menu of the utility.
The RAID BIOS setup screens shown in this section are for reference only, and
may not exactly match the items on your screen.
[F6] Back [F7] Finish [TAB] Navigate [
↑↓
] Select [ENTER] Popup
At the bottom of the screen are the navigation keys. These keys allow you to move
through and select menu options.
NVIDIA RAID Utility Oct 5 2004
- Dene a New Array -
RAID Mode: Striping Striping Block: Optimal
Free Disks Array Disks
Loc Disk Model Name Loc Disk Model Name
1.0.M XXXXXXXXXXXXXXXXXX
1.1.M XXXXXXXXXXXXXXXXXX [
→
] Add
2.0.M XXXXXXXXXXXXXXXXXX
2.1.M XXXXXXXXXXXXXXXXXX
[
←
] Del
Creating a RAID Volume
To create a RAID volume:
1. From the NVIDIA
®
RAID utility Dene a New Array menu, select RAID Mode
then press <Enter>. The following submenu appears.
Use the up or down arrow keys to select a
RAID mode then press <Enter>.
Mirroring
Striping
Stripe Mirroring
Spanning
To Next Page
