2-18 Chapter 2: Hardware information
PCI Express x 4 slot
PCI Express x16 slot
(at x16 speed)
PCI slots
PCI Express x1 slot
PCI Express x1 slot
PCI slots
2.5.5 PCI Express x4 slot & PCI Express x1 slot
This motherboard supports PCI Express x4 and PCI Express x1 network cards,
SCSI cards and other cards that comply with the PCI Express specications. Refer
to the gure below for the location of the slot.
2.5.6 PCI Express x16 slots
This motherboard supports PCI Express x16 graphics cards that comply with the
PCI Express specications. Refer to the gure below for the location of the slots.
