ASUS M2N-E 4-23
4.4.4 CPU Conguration
Select Menu
Item Specic Help
DRAM timing and control.
CPU Conguration
CPU Type AMD Engineering Sample
CPU Speed 2600 MHz
Cache RAM 1024K
DRAM Conguration
AMD Cool ‘n’ Quiet Function [Enabled]
Phoenix-Award BIOS CMOS Setup Utility
Advanced
F1:Help ↑↓ : Select Item -/+: Change Value F5: Setup Defaults
ESC: Exit →←: Select Menu Enter: Select Sub-menu F10: Save and Exit
Select Menu
Item Specic Help
Setting platform Memclock
or limit value.
DRAM Conguration
Memory Clock Frequency [Auto]
Tcl [Auto]
Trcd [Auto]
Trp [Auto]
Tras [Auto]
1T/2T Memory Timing [Auto]
Advance Memory Settings
DRAM Timing Control
Output Driver Control
Current DRAM Timing 533MHz-4-4-4-12-2T
Phoenix-Award BIOS CMOS Setup Utility
Advanced
DRAM Conguration
The items in the sub-menu show the DRAM-related information auto-detected by
the BIOS.
Memory Clock Frequency [Auto]
Sets the memory clock frequency.
Conguration options: [Auto] [DDR2 400] [DDR2 533] [DDR2 667] [DDR2 800]
Tcl [Auto]
Conguration options: [Auto] [3] [4] [5] [6]
Trcd [Auto]
Conguration options: [Auto] [3] [4] [5] [6]
Trp [Auto]
Conguration options: [Auto] [3] [4] [5] [6]
Tras [Auto]
Conguration options: [Auto] [5] [6] [7] ~ [18]
1T/2T Memory Timing [Auto]
Conguration options: [Auto] [1T] [2T]
