SS: Single-sided / DS: Double-sided
DIMM support:
• A*: Supports one module inserted into either slot as the single-channel memory
conguration.
• B*: Supports one pair of modules inserted into both the yellow slots as one pair of
dual-channel memory conguration.
Visit the ASUS website at www.asus.com for the latest QVL.
• DDR2 1066 is supported by AM2+ CPU only.
• The default DIMM frequency depends on its Serial Presence Detect (SPD), which is the
standard way of accessing information from a memory module. Under the default state,
some memory modules for overclocking may operate at a lower frequency than the
vendor-marked value.
1.5 Expansion slots
In the future, you may need to install expansion cards. The following sub-sections describe
the slots and the expansion cards that they support.
Unplug the power cord before adding or removing expansion cards. Failure to do so may
cause you physical injury and damage motherboard components.
1.5.1 Installing an expansion card
To install an expansion card:
1. Before installing the expansion card, read the documentation that comes with it and
make the necessary hardware settings for the card.
2. Remove the chassis cover (if your motherboard is already installed in a chassis).
3. Remove the bracket opposite the slot that you intend to use.
4. Align the card connector with the slot and press rmly until the card is completely
seated on the slot.
5. Secure the card to the chassis with the screw.
6. Replace the chassis cover.
DDR2-1066MHz capability
Vendor Part No. Size
SS/
DS
CL Chip No.
Chip
Brand
DIMM support
A* B*
Corsair CM2X1024-8500C5 1G DS N/A Heat-Sink Package N/A • •
GEIL GB24GB8500C5QC 1G SS 5 GL2L128M88BA25AB GEIL • •
1-6ASUS M2N68-AM SE2
