Asus M5A87 User Manual

ASUS M5A87 2-21
Power on By PS/2 Keyboard [Disabled]
Enables or disables PS/2 Keyboard to generate a wake event.
Conguration options: [Disabled] [Space Bar] [Power Key] [Ctrl-Esc]
Power On By PS/2 Mouse [Disabled]
When set to [Enabled], this parameter allows you to use the PS/2 mouse to turn on the
system. This feature requires an ATX power supply that provides at least 1A on the +5VSB
lead. Conguration options: [Disabled] [Enabled]
Power on From S5 By RTC Alarm [Disabled]
Enables or disables RTC to generate a wake event. Conguration options: [Disabled]
[Enabled]
2.6.5 HW Monitor Conguration
CPU Temperature [xxxºC/xxxºF] or [Ignored]
MB Temperature [xxxºC/xxxºF] or [Ignored]
The onboard hardware monitor automatically detects and displays the motherboard and CPU
temperatures. Select Ignored if you do not wish to display the detected temperatures.
CPU / Chassis / Power Fan Speed [N/A], [xxxxRPM], or [Ignored]
The onboard hardware monitor automatically detects and displays the CPU / Chassis / Power
fan speeds in rotations per minute (RPM). If the fan is not connected to the motherboard, the
eld shows N/A. Select [gnored] if you do not want the detected speed to be displayed.
VCORE Voltage, 3.3V Voltage, 5V Voltage, 12V Voltage [xx.xxxV] or [Ignored]
The onboard hardware monitor automatically detects the voltage output through the onboard
voltage regulators.
CPU Q-Fan Function [Enabled]
Enables or disables the ASUS Q-Fan feature that smartly adjusts the CPU fan speeds for
more efcient system operation. Conguration options: [Disabled] [Enabled]
The following item appears only when you set CPU Q-Fan Function to [Enabled].
CPU Fan Speed Low Limit [200 RPM]
Allows you to manually set a lower limit for the CPU fan speed. If the CPU fan speed is below the
specied limit, the system sends out warning beeps. Conguration options: [500 RPM] [400 RPM]
[300 RPM] [200 RPM] [100 RPM] [Ignored]
CPU Q-Fan Mode [Standard]
Allows you to set the appropriate performance level of the CPU fan.
[Standard] Sets to [Standard] to make the CPU fan automatically adjust depending on the
CPU temperature.
[Silent] Sets to [Silent] to minimize the fan speed for quiet CPU fan operation.
[Turbo] Set to [Turbo] to achieve maximum CPU fan speed.
[Manual] Allows you to individually set the CPU fan parameters.
2.6.6 Anti Surge Support [Enabled]
Allows you to enable or disable the Anti-Surge protection feature.
Conguration options: [Disabled] [Enabled]

Asus M5A87 Specifications

General

ECC	Yes
Number of memory slots	4
Supported memory types	DDR3-SDRAM
Maximum internal memory	16 GB
Supported memory clock speeds	1066, 1333, 1600, 2000 MHz
System bus rate	5.2 GT/s
Processor socket	Socket AM3
Processor manufacturer	AMD
Compatible processor series	AMD Phenom II X2, AMD Phenom II X3, AMD Phenom II X4, AMD Phenom II X6, AMD Phenom II X8
Number of SATA II connectors	6
Number of Parallel ATA connectors	0
Headphone outputs	3
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	2
Audio chip	Realtek ALC887
Component for	PC
Motherboard chipset	AMD 870 (RX881)
Audio output channels	7.1 channels
Motherboard form factor	ATX
RAID levels	0, 1, 5, 10, JBOD
Supported storage drive interfaces	SATA III
On-board graphics card	-
Parallel processing technology support	Not supported
PCI Express slots version	2.0
Controller interface type	AMD SB850
LAN controller	Realtek RTL8111E
Networking features	Gigabit Ethernet
Ethernet interface type	Fast Ethernet, Gigabit Ethernet
BIOS type	AMI
ACPI version	2.0a
BIOS memory size	16 Mbit

Weight and Dimensions

Depth	213 mm
Width	305 mm
