ASUS MAXIMUS V EXTREME
7-1
Chapter 7
Intel
®
technologies
7
7.1 Intel
®
2012 Desktop responsiveness technologies
This section details the overview of the installation and conguration procedures of the Intel®
2012 Desktop responsiveness technologies.
Intel
®
2012 Desktop responsiveness technologies feature the three technologies:
Intel
®
Smart Response Technology
Intel
®
Rapid Start Technology
Intel
®
Smart Connect Technology
System Requirements
In order for the system to run smoothly for the Intel
®
2012 Desktop responsiveness, your
system must meet the following requirements.
CPU: Intel
®
3rd/2nd generation Core Processor family
OS: Windows
®
7 operating systems
SSD: One dedicated SSD (Solid State Disk) to support Intel
®
Smart Response and
Intel
®
Rapid Start Technology is necessary.
Refer to the SSD Capacity Requirements table for the information of SSD size,
partition capacity, and system memory requirements.
HDD: At least one HDD (Hard Disk Drive) for the system OS drive.
DRAM: To enable Intel
®
Rapid Start Technology, DRAM size smaller than 8GB is
required.
Ensure to enable the acceleration of Intel
®
Smart Response Technology before creating
the partition for the Intel
®
Rapid Start Technology.
•
•
•
Chapter 7: Intel
®
technologies

Asus Maximus V Extreme Specifications

General

ECC	No
Non-ECC	Yes
Memory channels	Dual-channel
Memory slots type	DIMM
Number of memory slots	4
Supported memory types	DDR3-SDRAM
Maximum internal memory	32 GB
Supported memory clock speeds	1066, 1333, 1600, 1866, 2133, 2200, 2400, 2600, 2666, 2800 MHz
Supported memory module capacities	1GB, 2GB, 4GB, 8GB
System bus rate	5 GT/s
Processor socket	LGA 1155 (Socket H2)
Processor manufacturer	Intel
Compatible processor series	Intel Core i3, Intel Core i5, Intel Core i7
Maximum number of SMP processors	1
USB 2.0 connectors	2
Number of SATA connectors	10
Number of SATA II connectors	3
Number of SATA III connectors	6
Number of Parallel ATA connectors	0
I/O ports	1 x Thunderbolt 1 x ROG Connect On/ Off
Manageability features	WfM2.0, DMI2.0, WOL by PME, PXE
HDMI version	1.4a
Headphone outputs	5
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Audio chip	Realtek ALC898
Cooling type	Passive
Component for	PC
Power source type	ATX
Motherboard chipset	Intel Z77
PC health monitoring	CPU, FAN, LED, Temperature
Audio output channels	7.1 channels
Motherboard form factor	Extended ATX
RAID levels	0, 1, 5, 10
Supported storage drive interfaces	SATA, SATA II, SATA III
Graphics card	HD Graphics
OpenGL version	4.2
DirectX version	11
Maximum resolution	2560 x 1600 pixels
Parallel processing technology support	2-Way CrossFireX, 2-Way SLI, 3-Way CrossFireX, 3-Way SLI, 4-Way CrossFireX, 4-Way SLI, LucidLogix Virtu, Quad-GPU CrossFireX, Quad-GPU SLI
PCI Express slots version	2.0, 3.0
PCI Express configurations	1x16, 2x8, 4x8
Cables included	SATA
Wi-Fi standards	802.11a, 802.11b, 802.11g
Bluetooth version	4.0
Networking features	Gigabit LAN
Ethernet interface type	Fast Ethernet, Gigabit Ethernet
BIOS type	EFI AMI
ACPI version	2.0a
BIOS memory size	64 Mbit

Weight and Dimensions

Depth	272 mm
Width	305 mm
