Asus P5KC User Manual

5-28 Chapter 5: Software support
If you want to boot the system from a hard disk drive included in a created RAID
set, copy rst the RAID driver from the support CD to a oppy disk before you
install an operating system to the selected hard disk drive. Refer to section “
5.5
Creating a RAID driver disk
” for details.
5.4 RAID congurations
The motherboard comes with the JMicron
®
JMB363 RAID controller that allows you
to congure Serial ATA hard disk drives as RAID sets.
5.4.1 RAID denitions
RAID 0
(Data striping) optimizes two identical hard disk drives to read and write
data in parallel, interleaved stacks. Two hard disks perform the same work as a
single drive but at a sustained data transfer rate, double that of a single disk alone,
thus improving data access and storage. Use of two new identical hard disk drives
is required for this setup.
RAID 1
(Data mirroring) copies and maintains an identical image of data from one
drive to a second drive. If one drive fails, the disk array management software
directs all applications to the surviving drive as it contains a complete copy of
the data in the other drive. This RAID conguration provides data protection and
increases fault tolerance to the entire system. Use two new drives or use an
existing drive and a new drive for this setup. The new drive must be of the same
size or larger than the existing drive.
JBOD
(Spanning) stands for Just a Bunch of Disks and refers to hard disk drives
that are not yet congured as a RAID set. This conguration stores the same data
redundantly on multiple disks that appear as a single disk on the operating system.
Spanning does not deliver any advantage over using separate disks independently
and does not provide fault tolerance or other RAID performance benets.
5.4.2 Installing Serial ATA hard disks
The motherboard supports Serial ATA hard disk drives. For optimal performance,
install identical drives of the same model and capacity when creating a disk array.
To install the SATA hard disks for a RAID conguration:
1. Install the SATA hard disks into the drive bays.
2. Connect the SATA signal cables.
3. Connect a SATA power cable to the power connector on each drive.

Asus P5KC Specifications

General

ECC	No
Non-ECC	Yes
Number of memory slots	6
Maximum internal memory	8 GB
Processor socket	LGA 775 (Socket T)
Processor manufacturer	Intel
Maximum number of SMP processors	1
Number of SATA connectors	5
Special features	ASUS Quiet Thermal Solution: - ASUS AI Gear2. - ASUS AI Nap. - ASUS Fanless Design: Heat-pipe solution. - ASUS Fanless Design: Stack Cool 2. - ASUS Q-Fan 2. ASUS Crystal Sound: - ASUS Noise Filter. ASUS EZ DIY: - ASUS Q-Connector. - ASUS O.C. Profile. - ASUS CrashFree BIOS 3. - ASUS EZ Flash 2. - ASUS AI Slot Detector.
Manageability features	WfM 2.0, DMI 2.0, WOL by PME, WOR by PME, PXE
Controller interface type	Serial ATA
Controller 2nd interface type	UltraDMA 133/100/66
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Motherboard form factor	ATX
Compatible operating systems	2 x PCI-E x16 1 x PCI-E x1 3 x PCI
Bundled software	Drivers ASUS PC Probe II ASUS Update ASUS AI Suite
BIOS memory size	64 Mbit

Weight and Dimensions

Depth	244 mm
Width	305 mm
