ASUS P5Q WS 3-17
3.4 Ai Tweaker menu
The Ai Tweaker menu items allow you to congure overclocking-related items.
Take caution when changing the settings of the Ai Tweaker menu items.
Incorrect eld values can cause the system to malfunction.
3.4.1 Congure System performance Settings
Ai Overclock Tuner [Auto]
Allows selection of CPU overclocking options to achieve desired CPU internal
frequency. Select either one of the preset overclocking conguration options:
Manual Allows you to individually set overclocking parameters.
Auto Loads the optimal settings for the system.
Scroll down to display the following items:
v02.61 (C)Copyright 1985-2008, American Megatrends, Inc.
Select Screen
Select Item
Enter Go to Sub Screen
+- Change Option
F1 General Help
F10 Save and Exit
ESC Exit
v02.61 (C)Copyright 1985-2008, American Megatrends, Inc.
BIOS SETUP UTILITY
Main Ai Tweaker Advanced Power Boot Tools Exit
Congure System Performance Settings
Ai Overclock Tuner [Auto]
Ratio CMOS Setting [Auto]
FSB Strap to North Bridge [Auto]
DRAM Frequency [Auto]
DRAM Timing Control [Auto]
1st Information : 5-5-5-15-3-44-5-3
2nd Information : 8-3-5-4-6-4-6
3rd Information : 13-5-1-6-6
DRAM Static Read Control [Auto]
DRAM Read Training [Auto]
MEM. OC Charger [Auto
Ai Clock Twister [Auto]
Ai Transaction Booster [Auto]
C/P : A1 A2 A3 A4
LVL : 12 12 12 12
******** Please key in numbers directly! ********
The default values of the following items vary depending on the CPU and
memory modules you install on the motherboard.
Options
Manual
Auto
CPU Voltage [Auto]
CPU GTL Reference(0/2) [Auto]
CPU GTL Reference(1/3) [Auto]
CPU PLL Voltage [Auto]
FSB Termination Voltage [Auto]
Memory Voltage [Auto]
NB Voltage [Auto]
NB GTL Reference [Auto]
SB Voltage [Auto]
PCIE SATA Voltage [Auto]
*************************************************
Load-Line Calibration [Auto]
CPU Spread Spectrum [Auto]
PCIE Spread Spectrum [Auto]
