5-36 Chapter 5: RAID conguration
3. The following screen appears. Select a channel and press <Enter> to enter
the setup.
The numbers of the channel depend on the controller.
5.4.1 RAID 1 volume
The RAID 1 feature supports simultaneous mirrored volumes with two disks.
The RAID 1 feature supports hot swap capability, so when a disk in an RAID
1 volume fails, you can easily restore the volume, and the swapped disk is
automatically re-mirrored.
To create a RAID 1 volume:
1. Turn on the system after installing all SAS hard disk drives.
2. During POST, press <Ctrl+C> to enter the SAS conguration utility.
LSI Corporation MPT SAS2 BIOS
MPT2BIOS-7.05.01.00 (2010.04.30)
Copyright 2000-2010 LSI Corporation.
Press Ctrl-C to start LSI Corp Conguration Utility...
To avoid data loss, do not turn off the system when rebuilding.
Esc = Exit Menu F1/Shift+1 = Help
Alt+N = Global Properties -/+ = Alter Boot Order Ins/Del = Alter Boot List
LSI Corp Cong Utility v7.07.00.00 (2010.04.30)
Adapter List Global Properties
Adapter PCI PCI PCI PCI FW Revision Status Boot
BUS Dev Fnc Slot Order
SAS 2008 01 00 00 00 8.00.00.00-IR Enabled 0
