2-12ASUS P8Q67-M DO Series
2.4 Ai Tweaker menu
The Ai Tweaker menu items allow you to congure overclocking-related items.
Be cautious when changing the settings of the Ai Tweaker menu items. Incorrect eld
values can cause the system to malfunction.
The conguration options for this section vary depending on the CPU and DIMM model you
installed on the motherboard.
Main
Ai Tweaker
Advanced Monitor Boot Tool
Exit
Version 2.00.1201. Copyright (C) 2010 American Megatrends, Inc.
Forces a DDR3 frequency slower than the
common tCK detected via SPD.
→←: Select Screen
↑↓: Select Item
Enter: Select
+/-: Change Opt.
F1: General Help
F2: Previous Values
F5: Optimized Defaults
F10: Save ESC: Exit
EFI BIOS Utility - Advanced Mode
To set a user password:
1. Select the
User Password item and press <Enter>.
2. From the
Create New Password box, key in a password, then press <Enter>.
3. Conrm the password when prompted.
To change a user password:
1. Select the
User Password item and press <Enter>.
2. From the
Enter Current Password box, key in the current password, then press
<Enter>.
3. From the
Create New Password box, key in a new password, then press <Enter>.
4. Conrm the password when prompted.
To clear the user password, follow the same steps as in changing a user password, but press
<Enter> when prompted to create/conrm the password. After you clear the password, the
User Password item on top of the screen shows Not Installed.
Target DRAM Speed : xxxxMHz
Memory Frequency Auto
iGPU Max. Frequency Auto
EPU Power Saving MODE Disabled
> GPU Boost
> DRAM Timing Control
> CPU Power Management
CPU Offset Mode Sign +
CPU Voltage 1.165V Auto
iGPU Offset Mode Sign +
iGPU Voltage Auto
DRAM Voltage 1.500V Auto
VCCIO Voltage 1.050V Auto
PCH Voltage 1.050V Auto
Load-Line Calibration Auto
