Chapter 2: BIOS information2-21
Uncongure AMT/ME [Disabled]
Sets this item to [Disabled] to uncongure AMT/ME without using a password or set it to
[Enabled] to use a password. Conguration options: [Enabled] [Disabled]
WatchDog Timer [Disabled]
When set to [Enabled], the WatchDog Timer will monitor the time taken for each task
performed by a software or hardware. Conguration options: [Enabled] [Disabled]
The following two items become congurable only when you set the WatchDog Timer item
to [Enabled].
OS WatchDog Timer [0]
Use the <+> and <-> keys to adjust the value or key in a number directly.
BIOS WatchDog Timer [0]
Use the <+> and <-> keys to adjust the value or key in a number directly.
2.5.10 Onboard Devices Conguration
HD Audio Controller [Enabled]
[Enabled] Enables the High Denition Audio Controller.
[Disabled] Disables the controller.
The following item appears only when you set the HD Audio Controller item to [Enabled].
Front Panel Type [HD]
Allows you to set the front panel audio connector (AAFP) mode to legacy AC’97 or high-
denition audio depending on the audio standard that the front panel audio module supports.
[HD] Sets the front panel audio connector (AAFP) mode to high denition audio.
[AC97] Sets the front panel audio connector (AAFP) mode to legacy AC’97
SPDIF Out Type [SPDIF]
[SPDIF] Sets to [SPDIF] for SPDIF audio output.
[HDMI] Sets to [HDMI] for HDMI audio output.
Asmedia USB 3.0 Controller [Enabled] (P8Q67-M DO/USB3/TPM only)
[Enabled] Enables the onboard USB 3.0 controller.
[Disabled] Disables the controller.
Asmedia USB 3.0 Battery Charging Support [Disabled] (P8Q67-M DO/USB3/
TPM only)
This item appears only when the ASMedia USB 3.0 Controller item is set to [Enabled].
[Enabled] Enables ASMedia USB 3.0 fast battery charging support for USB 3.0
devices complying with the BC 1.1 regulation.
[Disabled] Disables this function.
