2-14 Chapter 2: Hardware information
Chapter 2
IRQ assignments for this motherboard
A B C D E F G H
Audio Controller shared
EHCI Controller shared
XHCI Controller shared
SATA Controller shared
PCIE x16_1 shared
PCIE x16_2 shared
PCIE x1_1
shared
PCIE x1_2
shared
PCI Slot 1
shared
PCI Slot 2
shared
PCI Slot 3 shared
Realtek 8111F (LAN) shared
Marvell SATA 6Gb/s
Controller
shared
ASM1042 shared
PCIe 3.0 support depends on CPU type and requires PCIe 3.0 VGA card.
In single VGA card mode, use the PCIe 3.0/2.0 x16_1 slot (blue) for a PCI Express
x16 graphics card to get better performance.
In CrossFireX™ mode, use the PCIe 3.0/2.0 x16_1 and PCIe 2.0 x16_2 slots for PCI
Express x16 graphics cards to get better performance.
We recommend that you provide sufcient power when running CrossFireX™ mode.
Connect a chassis fan to the motherboard connector labeled CHA_FAN1/2 when
using multiple graphics cards for better thermal environment. See pagg 2-23 for
details.
