Asus P8Z77-V LE User Manual

ix
P8Z77-V LE specications summary
(continued on the next page)
CPU LGA1155 socket for Intel
®
3
rd
/ 2
nd
Generation Core™ i7 / Core™
i5 / Core™ i3 / Pentium
®
/ Celeron
®
processors
Supports 22nm / 32nm CPU
Supports Intel
®
Turbo Boost technology 2.0*
* The Intel
®
Turbo Boost technology 2.0 support depends on the CPU
types.
** Refer to www.asus.com for Intel
®
CPU support list.
Chipset Intel
®
Z77 Express Chipset
Memory 4 x DIMMs, max. 32GB, DDR3 2400(O.C.)* / 2200(O.C.)* / 2133(O.C.) /
1866 (O.C.) / 1600 / 1333 / 1066 MHz, non-ECC, un-buffered memory
Dual-channel memory architecture
Supports Intel
®
Extreme Memory Prole (XMP)
* Hyper DIMM support is subject to the physical characteristics of
individual CPUs. Please refer to Memory QVL for details.
Graphics Integrated Graphics Processor - Intel
®
HD Graphics support
Multi-VGA output support: DisplayPort, HDMI, DVI, RGB port
- Supports DisplayPort with max.resolution up to 2560 x 1600 @60Hz
- Supports HDMI with max.resolution up to 1920 x 1200 @60Hz
- Supports DVI with max. resolution up to 1920 x 1200 @60Hz
- Supports RGB with max. resolution up to 2048 x 1536 @75Hz
- Supports Intel
®
InTru
TM
3D / Insider
TM
/ Quick Sync Video / Clear
Video HD Technology / HD Graphics
- Maximum shared memory of 1696MB
Multi-GPU
support
Supports ATI
®
Quad-GPU CrossFireX
TM
Technology*
Supports LucidLogix Virtu MVP Technology**
* Disable PCIe x1_1 and PCIe x1_2 slots and manual set the PCIe
x16_2 to x4 mode in BIOS when congure CrossFireX™ with dual
graphics cards.
** LucidLogix Virtu MVP supports Windows
®
7 Operating Systems.
Expansion
slots
1 x PCI Express 3.0* / 2.0 x16 slot (blue @x16 mode)
1 x PCI Express 2.0 x16 slot (black, max. @ x4 mode, compatible with
PCIe x1 and PCIe x4 devices)**
2 x PCI Express 2.0 x1 slots
3 x PCI slots
* PCIe 3.0 speed is supported by Intel
®
3
rd
generation Core
TM
processors.
** The PCIe x16_2 slot shares the bandwidth with the PCIe x1_1 slot and
PCIe x1_2 slot. The default setting is x2 mode. Go to the BIOS setup
to change the settings.

Asus P8Z77-V LE Specifications

General

ECC	No
Non-ECC	Yes
Memory voltage	1.5 V
Memory channels	Dual-channel
Memory slots type	DIMM
Number of memory slots	4
Supported memory types	DDR3-SDRAM
Maximum internal memory	32 GB
Supported memory clock speeds	1066, 1333, 1600, 1800, 1866, 2000, 2133, 2200, 2400 MHz
Supported memory module capacities	16GB, 1GB, 2GB, 4GB, 8GB
System bus rate	5 GT/s
Processor socket	LGA 1155 (Socket H2)
Processor manufacturer	Intel
Compatible processor series	Intel Core i3, Intel Core i5, Intel Core i7
Maximum number of SMP processors	1
Number of SATA III connectors	3
Number of Parallel ATA connectors	0
Headphone outputs	6
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Audio chip	Realtek ALC892
Cooling type	Passive
Component for	PC
Motherboard chipset	Intel Z77
PC health monitoring	CPU, FAN, Temperature
Audio output channels	7.1 channels
Motherboard form factor	ATX
RAID levels	0, 1, 5, 10
Supported storage drive interfaces	SATA II, SATA III
Cables included	SATA
Graphics card	HD Graphics
OpenGL version	3.2
DirectX version	11
Maximum resolution	2560 x 1600 pixels
Maximum graphics card memory	1696 MB
Parallel processing technology support	2-Way CrossFireX, LucidLogix Virtu, Quad-GPU CrossFireX
PCI Express slots version	2.0, 3.0
PCI Express configurations	1x4, 1x16
Controller 2nd interface type	Marvell PCIe SATA 6Gb/s
LAN controller	Realtek RTL8111F
Wi-Fi standards	Not supported
Networking features	Gigabit LAN
Ethernet interface type	Gigabit Ethernet
BIOS type	EFI AMI
ACPI version	2.0a
BIOS memory size	64 Mbit

Weight and Dimensions

Depth	244 mm
Width	305 mm
