2.3
Building your computer system
2.3.1
Additional tools and components to build a PC
system
1 bag of screws
Philips (cross) screwdriver
PC chassis
Power supply unit
Intel LGA 201
1 CPU
Intel LGA 201
1 compatible CPU Fan
DIMM
SA
T
A hard disk drive
SA
T
A optical disc drive (optional)
Graphics card
The tools and components in the table above are not included in the motherboard package.
