Asus P9X79 LE User Manual

ASUS P9X79 LE 2-19
Chapter 2
2.2.6 Onboard LEDs
1. Standby Power LED
The Standby Power LED will light up once the system is connected to a power source.
3. BIOS Flashback switch
USB BIOS Flashback allows you to easily update the BIOS without entering the
BIOS or operating system. Just connect the USB storage device containing the BIOS
le to the USB port, press the BIOS Flashback switch, and the BIOS is updated
automatically.
Refer to section 2.3.10 USB BIOS Flashback for more information about BIOS_FLBK
switch.

Asus P9X79 LE Specifications

General

Chipset	Intel X79
CPU Socket	LGA 2011
Memory Type	DDR3
Memory Slots	8
Maximum Memory	64 GB
Storage Interface	4 x SATA 6Gb/s, 4 x SATA 3Gb/s
Form Factor	ATX
Audio	Realtek ALC892 8-Channel High Definition Audio CODEC
LAN	Realtek 8111E Gigabit LAN
USB Ports	4 x USB 3.0, 12 x USB 2.0
Expansion Slots	3 x PCIe 3.0/2.0 x16, 2 x PCIe 2.0 x1, 1 x PCI
