3-32 Chapter 3: BIOS setup
Chapter 3
SATA Mode [AHCI Mode]
Allows you to set the SATA conguration.
[Disabled] Disables the SATA function.
[IDE Mode] Set to [IDE Mode] when you want to use the Serial ATA hard disk drives as
Parallel ATA physical storage devices.
[AHCI Mode] Set to [AHCI Mode] when you want the SATA hard disk drives to use the
AHCI (Advanced Host Controller Interface). The AHCI allows the onboard
storage driver to enable advanced Serial ATA features that increases
storage performance on random workloads by allowing the drive to
internally optimize the order of commands.
[RAID Mode] Set to [RAID Mode] when you want to create a RAID conguration from the
SATA hard disk drives.
The following items appear only when you set the previous item to [IDE Mode].
Serial-ATA Controller 0 [Enhanced]
Allows you to enabled/disabled the Serial-ATA Controller 0.
Conguration options: [Disabled] [Enhanced] [Compatible]
Serial-ATA Controller 1 [Enhanced]
Allows you to enabled/disabled the Serial-ATA Controller 1.
Conguration options: [Disabled] [Enhanced]
S.M.A.R.T. Status Check [Enabled]
S.M.A.R.T. (Self-Monitoring, Analysis and Reporting Technology) is a monitor system. When
read/write of your hard disk errors occur, this feature allows the hard disk to report warning
messages during the POST.
Conguration options: [Disabled] [Enabled]
SATA6G_1 (Gray)
Hot Plug [Disabled]
This item appear only when you set the previous item to [AHCI Mode] and [RAID Mode].
It’s allow user to enabled/disabled SATA Hot Plug Support. Conguration options: [Disabled]
[Enabled].
SATA6G_2 (Gray)
Hot Plug [Disabled]
This item appear only when you set the previous item to [AHCI Mode] and [RAID Mode].
It’s allow user to enabled/disabled SATA Hot Plug Support. Conguration options: [Disabled]
[Enabled].
