Asus PQ321QE User Manual

28
E
Specications
nProduct Series
PQ321QE
Display Panel Size(diagonal) 31.5” (80.1 cm) 16:9
Display Viewing Area(HxV) 697.92 x 392.58
Panel Backlight/ Type W-LED / IGZO
Display Surface(non-glare/ glare) Non-glare
Color Saturation 80% (CIE 1976), 72% (CIE 1931)
True Resolution 3840 x 2160
Pixel Pitch 0.182 mm
Brightness (Max.) 350 cd/m2
Contrast Ratio (Typ.) 800:1
Viewing Angle (CR≧10) 176 / 176
Display Colors 1073.7 M (10 bits)
Response Time 8ms (Gray to Gray)
Audio Features Stereo Speaker 2W x 2 stereo, RMS
Input PC DisplayPort x 1
Audio 3.5mm mini stereo jack x 1
Serial (RS-232C) 3.5mm mini jack x 1
Output Audio 3.5mm mini stereo jack x 1
Power Power Consumption* 99W
Power Saving Mode < 0.5W
Power Off Mode < 0.5W
Voltage 100-240V, 50/60 Hz
Mechanical Design Tilt(angle) +25 ~ -5
Swivel(angle) +45 ~ -45
Height Adjustment (mm) 150 mm
VESA Wall Mounting(mm) 200 x 200 mm
Security Kensington lock Yes
Dimension Phys. Dimension with
Stand(WxHxD)
750 x 489 x 256 mm
Phys. Dimension without Stand
(WxHxD) (For VESA Wall Mount)
750 x 441 x 35 mm
Box Dimension (WxHxD) 990 x 558 x 230 mm
Weight Net Weight (Esti.) 13 Kg
Gross Weight (Esti.) 17 Kg
Accessories AC adapter, Power cord, DisplayPort cable, Warranty Card, Setup
Manual, RS-232C conversion cable (Φ3.5 mini-jack),Cable clamp,
Horizontal sticker (Operation buttons)
Regulation Approval WEEE, RoHS, CE, EAC
*1 When using the monitor in DC19 V : 88 W
As a part of our policy of continuous improvement, ASUS reserves the right to make design and specication changes for
product improvement without prior notice. The performance specication gures indicated are nominal values of production
units. There may be some deviations from these values in individual units.

Asus PQ321QE Specifications

General

Brand	Asus
Model	PQ321QE
Category	Monitor
Language	English
