Supplied Components
If any component should be missing, please contact your dealer.

Liquid Crystal Display Monitor: 1

Power cord: 3

AC adapter: 1

Setup Manual: 1

DisplayPort cable: 1

RS-232C conversion cable (Φ3.5 mini-jack): 1

Pedestal (for stand): 1

Strut (for stand): 1

Attachment plate (for stand): 1 (preinstalled on monitor)

Countersunk screws (M4 x 6 without washers): 5

Screws (M4 x 10 with washers): 4

Hex wrench: 1

Cable clamp: 2

Cable clamp (small): 1

Cable clamp (large): 2

Horizontal sticker (Operation buttons): 1
