ASUS Pro WS X299 SAGE II
2-9
Chapter 2
2.1.7 Front I/O connector
USB 3.2 Gen 2
To install USB 3.2 Gen 2 connectorTo install ASUS Q-Connector
This connector will only t in one
orientation. Push the connector until it
clicks into place.
AAFP
To install front panel audio connector
USB 3.2 Gen 1
To install USB 3.2 Gen 1 connector
