Asus ROG RAMPAGE VI EXTREME User Manual

3-10
Chapter 3: BIOS Setup
Chapter 3
4. Select a Main Cooling System BOX cooler, Tower cooler, Water cooler, or I’m not
sure, then click Next.
5. After selecting the Main Cooling System, click Next then click Yes to start the OC
Tuning.
Creating RAID
To create RAID:
1. Press <F11> on your keyboard or click
from the BIOS screen to open
EZ Tuning Wizard screen.
2. Click RAID
then click Next.
• Ensure that your HDDs have no existing RAID volumes.
• Ensure to connect your HDDs to Intel
®
SATA connectors.
3. Select the port that you want to set to [RAID] mode, PCIE or SATA, then click Next.

Asus ROG RAMPAGE VI EXTREME Specifications

General

Form Factor	E-ATX
Chipset	Intel X299
Socket	LGA 2066
Memory Channels	Quad Channel
Memory Support	DDR4
Memory Speed	4133+(OC) MHz
Storage	1 x U.2
USB Ports	4 x USB 2.0
Networking	Intel I219V
Audio	ROG SupremeFX 8-Channel High Definition Audio CODEC
RGB Lighting	Aura Sync RGB
PCIe Slots	4 x PCIe 3.0 x16, 1 x PCIe 3.0 x4
