Asus RT-AC3100 User Manual

12
1.6 Router Setup
IMPORTANT!
• Useawiredconnectionwhensettingupyourwirelessrouterto
avoid possible setup problems.
• BeforesettingupyourASUSwirelessrouter,dothefollowing:
 • Ifyouarereplacinganexistingrouter,disconnectitfromyour
network.
 • Disconnectthecables/wiresfromyourexistingmodemsetup.If
your modem has a backup battery, remove it as well.
 • Rebootyourcablemodemandcomputer(recommended).
1.6.1 Wired connection
NOTE: You can use either a straight-through cable or a crossover cable
for wired connection.
To set up your wireless router via wired connection:
1. Insert your wireless router’s AC adapter to the DC-IN port and
plug it to a power outlet.
RT-AC88U
Computer
Wall Power Outlet
Modem
Power
LAN
WAN
E10302_RT-AC88U_manual.indd 12 2015/5/11 15:40:52

Asus RT-AC3100 Specifications

General

Color	black
Wi-Fi Mesh System	yes
Band Technology	dual
Frequency Band	2.4 ghz, 5.0 ghz
Beamforming	yes
Ethernet Standard	10/100/1000
Ethernet Switch	yes
Wireless Networking Standard	wi-fi 5
Wireless Standard	ac, n
2.4 Ghz Streams	1
5.0 Ghz Streams	1
Gigabit Ethernet Speed	yes
Antennas	4
Parental Control	yes
Firewall	spi
Data Encryption	yes
Encryption Type	wep, wpa2-psk, wpa-psk, wpa-enterprise, wpa2-enterprise
Security Features	64- and 128-bit wep, wpa2-psk, wpa-psk, wpa-enterprise and wpa2-enterprise
Ports	rj-45, usb
LAN Ports	4
WAN Ports	1
Built In Modem	yes
Bluetooth	no
Smart Applications	true, asus router

Weight and Dimensions

Height	7.4 inches
Width	11.81 inches
Net Weight	2 pounds
