Asus RT-AC88U User Manual

25
IMPORTANT! You first need to create a share account and its
permission /access rights to allow other network clients to access the
USB device via an FTP site/third-party FTP client utility, Servers Center,
Samba, or AiCloud. For more details, refer to the section 3.5 Using the
USB Application and 3.6 Using AiCloud in this user manual.
To monitor your USB device:
1. From the navigation panel, go to General > Network Map.
2. OntheNetworkMapscreen,selecttheUSB Disk Status icon
to display your USB device’s information.
3. On the AiDisk Wizard field, click GO to set up an FTP server for
Internet file sharing.
NOTES:
• Formoredetails,refertothesection3.5.2 Using Servers Center in
this user manual.
• ThewirelessrouterworkswithmostUSBHDDs/Flashdisks(upto
4TB size) and supports read-write access for FAT16, FAT32, NTFS, and
HFS+.
E10302_RT-AC88U_manual.indd 25 2015/5/11 15:40:54

Asus RT-AC88U Specifications

General

Output current	2.37 A
Output voltage	19 V
AC input voltage	110 - 240 V
Power source type	AC
AC input frequency	50 - 60 Hz
Product type	Tabletop router
On/off switch	Yes
Product color	Black, Red
LED indicators	LAN, Power, USB, WAN, WLAN, WPS
Wi-Fi band	Dual-band (2.4 GHz / 5 GHz)
Wi-Fi standards	802.11a, Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Top Wi-Fi standard	Wi-Fi 5 (802.11ac)
WLAN data transfer rate (max)	1750 Mbit/s
Bandwidth (first)	2.4 GHz
Bandwidth (second)	5 GHz
WLAN data transfer rates supported	1, 2, 5.5, 6, 9, 12, 18, 24, 36, 48, 54, 600, 1750 Mbit/s
Antennas quantity	4
Ethernet LAN interface type	Gigabit Ethernet
USB 2.0 ports quantity	2
Ethernet LAN (RJ-45) ports	8
Processor frequency	1400 MHz
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	74 mm
Width	118 mm
Height	33 mm
Weight	110 g
