Asus RT-AC88U User Manual

91
4.7.4 Restore/Save/Upload Setting
To restore/save/upload wireless router settings:
1. From the navigation panel, go to Advanced Settings >
Administration > Restore/Save/Upload Setting tab.
2. Select the tasks that you want to do:
• Torestoretothedefaultfactorysettings,clickRestore, and
click OK in the confirmation message.
• Tosavethecurrentsystemsettings,clickSave, navigate to
the folder where you intend to save the file and click Save.
• Torestorefromasavedsystemsettingsle,clickBrowse to
locate your file, then click Upload.
If issues occur, upload the latest firmware version and configure new
settings. Do not restore the router to its default settings.
E10302_RT-AC88U_manual.indd 91 2015/5/11 15:40:59

Asus RT-AC88U Specifications

General

Output current	2.37 A
Output voltage	19 V
AC input voltage	110 - 240 V
Power source type	AC
AC input frequency	50 - 60 Hz
Product type	Tabletop router
On/off switch	Yes
Product color	Black, Red
LED indicators	LAN, Power, USB, WAN, WLAN, WPS
Wi-Fi band	Dual-band (2.4 GHz / 5 GHz)
Wi-Fi standards	802.11a, Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Top Wi-Fi standard	Wi-Fi 5 (802.11ac)
WLAN data transfer rate (max)	1750 Mbit/s
Bandwidth (first)	2.4 GHz
Bandwidth (second)	5 GHz
WLAN data transfer rates supported	1, 2, 5.5, 6, 9, 12, 18, 24, 36, 48, 54, 600, 1750 Mbit/s
Antennas quantity	4
Ethernet LAN interface type	Gigabit Ethernet
USB 2.0 ports quantity	2
Ethernet LAN (RJ-45) ports	8
Processor frequency	1400 MHz
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	74 mm
Width	118 mm
Height	33 mm
Weight	110 g
