Asus RT-AC88U User Manual

9
NOTES:
• Useonlytheadapterthatcamewithyourpackage.Usingother
adapters may damage the device.
• Specifications:
DC Power adapter DC Output: +19V with max 2.37A/3.42A current
Operating
Temperature
0~40
o
C Storage 0~70
o
C
Operating Humidity 50~90% Storage 20~90%
WPS LED On/Off button
Press this button to turn on/off the WPS LED on the panel.
Wi-Fi On/Off button
Press this button to turn on /off the Wi-Fi connection.
Reset button
This button resets or restores the system to its factory default settings.
WPS button
This button launches the WPS Wizard.
USB 2.0 port
Insert USB 2.0 devices such as USB hard disks or USB flash drives into this port.
LAN 1 ~ 8 ports
Connect network cables into these ports to establish LAN connection.
WAN (Internet) port
Connect a network cable into this port to establish WAN connection.
Power (DC-IN) port
Insert the bundled AC adapter into this port and connect your router to a power source.
Power button
Press this button to power on or off the system.
E10302_RT-AC88U_manual.indd 9 2015/5/11 15:40:51

Asus RT-AC88U Specifications

General

Output current	2.37 A
Output voltage	19 V
AC input voltage	110 - 240 V
Power source type	AC
AC input frequency	50 - 60 Hz
Product type	Tabletop router
On/off switch	Yes
Product color	Black, Red
LED indicators	LAN, Power, USB, WAN, WLAN, WPS
Wi-Fi band	Dual-band (2.4 GHz / 5 GHz)
Wi-Fi standards	802.11a, Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Top Wi-Fi standard	Wi-Fi 5 (802.11ac)
WLAN data transfer rate (max)	1750 Mbit/s
Bandwidth (first)	2.4 GHz
Bandwidth (second)	5 GHz
WLAN data transfer rates supported	1, 2, 5.5, 6, 9, 12, 18, 24, 36, 48, 54, 600, 1750 Mbit/s
Antennas quantity	4
Ethernet LAN interface type	Gigabit Ethernet
USB 2.0 ports quantity	2
Ethernet LAN (RJ-45) ports	8
Processor frequency	1400 MHz
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	74 mm
Width	118 mm
Height	33 mm
Weight	110 g
