Asus RT-AC88U User Manual

75
4. On the Trigger Port List table, key in the following
information:
• Description: Enter a short name or description for the
service.
• Trigger Port: Specify a trigger port to open the incoming
port.
• Protocol: Select the protocol, TCP, or UDP.
• Incoming Port: Specify an incoming port to receive inbound
data from the Internet.
• Protocol: Select the protocol, TCP, or UDP.
5. Click the Add to enter the port trigger information to the
list. Click the Delete button to remove a port trigger entry
from the list.
6. When done, click Apply.
NOTES:
• WhenconnectingtoanIRCserver,aclientPCmakesanoutgoing
connection using the trigger port range 66660-7000. The IRC server
responds by verifying the username and creating a new connection
to the client PC using an incoming port.
• IfPortTriggerisdisabled,therouterdropstheconnectionbecause
it is unable to determine which PC is requesting for IRC access.
When Port Trigger is enabled, the router assigns an incoming port to
receive the inbound data. This incoming port closes once a specific
time period has elapsed because the router is unsure when the
application has been terminated.
• Porttriggeringonlyallowsoneclientinthenetworktousea
particular service and a specific incoming port at the same time.
• Youcannotusethesameapplicationtotriggeraportinmorethan
one PC at the same time. The router will only forward the port back
to the last computer to send the router a request/trigger.
E10302_RT-AC88U_manual.indd 75 2015/5/11 15:40:58

Asus RT-AC88U Specifications

General

Output current	2.37 A
Output voltage	19 V
AC input voltage	110 - 240 V
Power source type	AC
AC input frequency	50 - 60 Hz
Product type	Tabletop router
On/off switch	Yes
Product color	Black, Red
LED indicators	LAN, Power, USB, WAN, WLAN, WPS
Wi-Fi band	Dual-band (2.4 GHz / 5 GHz)
Wi-Fi standards	802.11a, Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Top Wi-Fi standard	Wi-Fi 5 (802.11ac)
WLAN data transfer rate (max)	1750 Mbit/s
Bandwidth (first)	2.4 GHz
Bandwidth (second)	5 GHz
WLAN data transfer rates supported	1, 2, 5.5, 6, 9, 12, 18, 24, 36, 48, 54, 600, 1750 Mbit/s
Antennas quantity	4
Ethernet LAN interface type	Gigabit Ethernet
USB 2.0 ports quantity	2
Ethernet LAN (RJ-45) ports	8
Processor frequency	1400 MHz
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	74 mm
Width	118 mm
Height	33 mm
Weight	110 g
