77
3. On the Famous Server List field, select the type of service
you want to access.
4. On the Famous Game List field, select the popular game that
you want to access. This item lists the port required for your
selected popular online game to work properly.
5. On the Port Forwarding List table, key in the following
information:
• Service Name: Enter a service name.
• Port Range: If you want to specify a Port Range for clients
on the same network, enter the Service Name, the Port
Range (e.g. 10200:10300), the LAN IP address, and leave the
Local Port empty. Port range accepts various formats such
as Port Range (300:350), individual ports (566,789) or Mix
(1015:1024,3021).
NOTES:
• Whenyournetwork’sfirewallisdisabledandyouset80astheHTTP
server’s port range for your WAN setup, then your http server/web
server would be in conflict with the routers web user interface.
• Anetworkmakesuseofportsinordertoexchangedata,witheach
port assigned a port number and a specific task. For example, port 80
is used for HTTP. A specific port can only be used by one application
or service at a time. Hence, two PCs attempting to access data
through the same port at the same time would fail. For example, you
cannot set up Port Forwarding for port 100 for two PCs at the same
time.
• Local IP: Key in the client’s LAN IP address.
NOTE: Use a static IP address for the local client to make port forwarding
work properly. Refer to section 4.2 LAN for information.
E10302_RT-AC88U_manual.indd 77 2015/5/11 15:40:58
