Asus RT-N65U User Manual

12
NOTES:
• For details on connecting to a wireless network, refer to the
WLAN adapter’s user manual.
• To set up the security settings for your network, refer to the
section Setting up the wireless security settings in this user
manual.
Before you proceed
A. Disable the proxy server, if enabled.
Windows
®
7
1. Click Start > Internet Explorer to
launch the browser.
2. Click Tools > Internet options >
Connections tab > LAN settings.
NOTE: Before conguring your wireless router, do the steps
described in this section for your host computer and network
clients.

Asus RT-N65U Specifications

General

VPN support	IPSec Pass-Throuth\\r PPTP Pass-Through\\r L2TP Pass-Through
Ethernet LAN	Yes
Cabling technology	10/100/1000Base-T(X)
Networking standards	IEEE 802.11a, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet LAN interface type	Gigabit Ethernet
Wi-Fi band	Dual-band (2.4 GHz / 5 GHz)
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Top Wi-Fi standard	Wi-Fi 4 (802.11n)
WLAN data transfer rate (max)	450 Mbit/s
Bandwidth	2.4 GHz
Input current	1.58 A
Rack mounting	No
Frequency band	2.4 & 5 GHz
USB ports quantity	2
WLAN data transfer rates supported	1, 2, 5.5, 6, 9, 12, 18, 24, 36, 48, 54, 450 Mbit/s
Ethernet LAN (RJ-45) ports	4
Antennas quantity	3
Security algorithms	128-bit WEP, 64-bit WEP, WPA-PSK, WPA2-PSK, WPS
AC input voltage	110 - 240 V
AC input frequency	50 - 60 Hz
Product color	Black
Cables included	LAN (RJ-45)

Weight and Dimensions

Depth	145 mm
Width	172 mm
Height	60 mm
Weight	375 g
