Asus RT-N65U User Manual

27
Using the Traffic Manager
Managing QoS (Quality of Service) Bandwidth
The Quality of Service (QoS) allows you to set the bandwidth
priority and manage the network traffic.
To set up the bandwidth priority:
1. Launch the wireless router’s web GUI.
2. On the Traffic Manager screen, select the QoS tab.
3. Click ON to enable the default rule and fill in the upload and
download bandwidth fields.
NOTE:
• Get the bandwidth information from your ISP.
• If you want to prioritize specific network applications and
network devices, select your preferred priority from the User-
defined QoS rules.

Asus RT-N65U Specifications

General

VPN support	IPSec Pass-Throuth\\r PPTP Pass-Through\\r L2TP Pass-Through
Ethernet LAN	Yes
Cabling technology	10/100/1000Base-T(X)
Networking standards	IEEE 802.11a, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet LAN interface type	Gigabit Ethernet
Wi-Fi band	Dual-band (2.4 GHz / 5 GHz)
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Top Wi-Fi standard	Wi-Fi 4 (802.11n)
WLAN data transfer rate (max)	450 Mbit/s
Bandwidth	2.4 GHz
Input current	1.58 A
Rack mounting	No
Frequency band	2.4 & 5 GHz
USB ports quantity	2
WLAN data transfer rates supported	1, 2, 5.5, 6, 9, 12, 18, 24, 36, 48, 54, 450 Mbit/s
Ethernet LAN (RJ-45) ports	4
Antennas quantity	3
Security algorithms	128-bit WEP, 64-bit WEP, WPA-PSK, WPA2-PSK, WPS
AC input voltage	110 - 240 V
AC input frequency	50 - 60 Hz
Product color	Black
Cables included	LAN (RJ-45)

Weight and Dimensions

Depth	145 mm
Width	172 mm
Height	60 mm
Weight	375 g
