Asus TUF Z370-PRO GAMING User Manual

ix
CPU
LGA1151 socket for 8th Gen Intel
®
Core™ Processor
Supports 14nm CPU
Supports Intel
®
Turbo Boost Technology 2.0*
* Support of these features depends on the CPU types. Refer to www.asus.com for
Intel
®
CPU support list.
Chipset
Intel
®
Z370 Chipset
Memory
4 x DIMM, max. 64GB, DDR4 4000(O.C.)* / 3866(O.C.)* / 3733(O.C.)* /
3600(O.C.)* / 3466(O.C.)* / 3400(O.C.)* / 3333(O.C.)* / 3300(O.C.)* /
3200(O.C.)*/3000(O.C.)*/2800(O.C.)*/2666/2400/2133MHz,
non-ECC, un-buffered memory
Dual channel memory architecture
Supports Intel
®
ExtremeMemoryProle(XMP)
* Hyper DIMM support is subject to the physical characteristics of individual
CPUs. Please refer to www.asus.com for Memory QVL (Qualified Vendors List)
for details.
Expansion Slots
2 x PCIe 3.0/2.0 x16 slots (supports x16, x8/x8, x8/x4+x4*, x8+x4+x4/x0**)
1 x PCI Express 3.0/2.0 x16 slot (max. at x2 mode, compatible with PCIe x1
and x2 devices)
3 x PCI Express 3.0/2.0 x1 slots
* For 2 Intel
®
SSD on CPU support, install a Hyper M.2 X16 card (sold separately)
into the PCIeX16_2 slot, enable this card under BIOS settings.
** For 3 Intel
®
SSD on CPU support, install a Hyper M.2 X16 card (sold separately)
into the PCIeX16_1 slot, enable this card under BIOS settings.
VGA
Integrated Graphics Processor- Intel
®
HD Graphics support
Multi-VGA output support: HDMI/DVI-D port
-SupportsHDMI1.4bwithmax.resolution4096x2160@24Hz/
2560x1600@60Hz
-SupportsDVI-Dwithmax.resolution1920x1200@60Hz
Supports Intel
®
InTru™ 3D/Quick Sync Video/Clear Video HD Technology/
Insider™
Maximum shared memory of 1024MB (for iGPU exclusively)
Multi-GPU
Support
Supports NVIDIA
®
2-Way/Quad-GPU SLI™ Technology
Supports AMD
®
2-Way/Quad-GPU CrossFireX™ Technology
LAN
Intel
®
I219-V Gigabit LAN- Dual interconnect between the integrated Media
Access Controller (MAC) and physical layer (PHY)
TUF LANGuard
ASUS Turbo LAN Utility
(continued on the next page)
TUF Z370-PRO GAMING specifications summary

Asus TUF Z370-PRO GAMING Specifications

General

RAID levels	0, 1, 5, 10
Supported storage drive types	HDD & SSD
Supported storage drive interfaces	M.2, SATA III
ECC	No
Non-ECC	Yes
Memory channels	Dual-channel
Memory slots type	DIMM
Number of memory slots	4
Supported memory types	DDR4-SDRAM
Maximum internal memory	64 GB
Supported memory clock speeds	2133, 4000 MHz
Audio chip	Realtek ALC887
Cooling type	Passive
Component for	PC
Motherboard chipset	Intel® Z370
PC health monitoring	CPU, FAN, Power supply, Temperature, Voltage
Audio output channels	7.1 channels
Motherboard form factor	ATX
Motherboard chipset family	Intel
Parallel processing technology support	2-Way CrossFireX, 2-Way SLI
Processor socket	LGA 1151 (Socket H4)
Compatible processor series	Intel Core i3, Intel Core i5, Intel Core i7
Maximum number of SMP processors	1
Number of M.2 (M) slots	2
PCI Express x1 (Gen 3.x) slots	3
BIOS type	UEFI
ACPI version	6.0
BIOS memory size	16 Mbit
System Management BIOS (SMBIOS) version	3.0
Cables included	SATA
LAN controller	Intel® I219-V
Ethernet interface type	Gigabit Ethernet
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Firewire (IEEE 1394) ports	0
Number of SATA III connectors	6

Weight and Dimensions

Depth	- mm
Width	244 mm
Height	305 mm
