2-1ASUS TUF Gaming Monitor VG27AQML1A series
2.1 Assembling the monitor arm/base
To assemble the monitor base:
1. Have the front of the monitor face down on a table.
2. Place the arm hinge of the stand assembly onto its compartment on the rear of
the monitor (for selected models).
3. Attach the base into the arm, making sure the tab on the arm fits into the groove
on the base.
4. Fix the base to the arm by fastening the bundled screw(s).
We recommend that you cover the table surface with soft cloth to prevent
damage to the monitor.
1
1
1
2
2
2
3
Hinge screw size: M4 x 10 mm.
Base screw size: M6 x 16.2 mm.
